Overview:
The DCS-SP series is purpose-built for high-volume, large-bag packaging of oil-seed meal products in food processing factories. Features an oversized hopper for super-large capacity filling.
Models and Key Specifications:
– DCS-70I-SP: 400-500 bags/hr; pack weight 50-70 kg
– DCS-70II-SP: 800-1000 bags/hr; pack weight 50-70 kg
– Material bulk density: 0.45-0.55 t/m3
– Accuracy grade: 0.2
– Bag size: 800-1250 (L) x 550-750 (W) mm
– Scale hopper volume: 170 L
Key Features:
– Single-axis dual-outlet, self-emptying automatic feeding
– Dedicated bag-clamping outlet
– RS232 communication interface; ultra-low false-alarm rate
– Anti-environmental-interference weighing structure
Applicable Materials:
– Soybean meal, rapeseed meal, cottonseed meal, and similar oil-seed meals
Working Environment:
– Temperature: -20 to 45 deg C; Humidity: max 95% (no condensation)
