Overview:
The DCS-SL series is the premium packaging scale for the feed industry. It integrates AS232 interface, high-precision 10,000-60,000 count accuracy, and IP68 waterproof protection for harsh feed plant environments.
Models and Key Specifications:
– DCS-50B-SL: 300-400 bags/hr
– DCS-50 II B-SL: 600-800 bags/hr
– Applicable materials: corn, soybean, rapeseed feed
– Bulk density: 450-550 kg/m3
– Pack weight: 20-50 kg
– Accuracy grade: 0.2
– Power: 380VAC, 50Hz, 3kVA
Key Features:
– AS232 dedicated interface; high precision 10,000-60,000 accuracy
– Anti-vibration and dust collector sensor
– Stainless steel construction; IP68 waterproof sensor protection
– Energy saving: saves more than 60% power vs. comparable products
– Node-type bag clamp; special-shaped bag outlet supported
– Convenient fork-type mounting
Working Environment:
– Temperature: -10 to 40 deg C; Relative humidity: 10-95%
