Overview:
The YCS30(H)-BU is a compact, high-precision liquid filling scale for small containers (barrels, cans, bottles) in the 20-50 kg range.
Key Specifications:
– Fill range: 20-50 kg per fill
– Flow rate: 10 m/hr
– Filling nozzle: DN50, 316 stainless steel
– Working pressure: 0-0.6 MPa
– Power: 220V AC (-15% to +10%), 50Hz, max 500W
Key Features:
– Product parameter storage: up to 10 product profiles
– Quick automatic calibration for stored product weights
– Auto zero-tracking after each fill cycle
– No-missing-count protection
– Cascade filling control to prevent undetected fill points
– Machine protection: auto shutoff on connection loss
Typical Applications:
Chemical small-barrel filling, food/beverage bottling, lubricant can filling, cleaning product packaging.
