Overview:
The DCS-HF series is a high-precision, high-speed electronic packaging scale specifically designed for chemical fertilizer and finished fertilizer packaging.
Models and Key Specifications:
– DCS-HF10: 500-600 bags/hr; 220VAC/50Hz/500W
– DCS-HF20: 1000-1200 bags/hr; 220VAC/50Hz/1000W
– Pack weight: 40-50 kg/bag
– Accuracy grade: 0.2
– Bag material: PP woven, PE inner bag
Key Features:
– Stainless steel frame; strong corrosion resistance
– Intelligent control with multiple auxiliary functions
– 3000:1 A/D conversion; TraxDSP anti-interference technology
– Weighing error display and correction function
– Standard RS232 communication interface
Applicable Materials:
– Lime, sodium chloride, dye powder, compound fertilizer
Working Environment:
– Temperature: -20 to 45 deg C; Relative humidity: max 95% (no condensation)
